Product DescriptionThe TeSys GV3P32 is a 3-pole thermal-magnetic manual motor starter. By consolidating specialized motor defense mechanisms into a standardized 55mm wide frame, it delivers full-spectrum safety against common electrical faults without requiring external inline overcurrent fuses.Key Features3-Pole (3P) Configuration: Simultaneously breaks and shields all three incoming live phase lines to preserve balanced power distribution across three-phase motor windings.Tunable Thermal Dial (23A to 32A): Features a front-accessible, analog tuning dial that allows an engineer to match the breaker’s overload response to the exact Full Load Amperage (FLA) of the machinery.Rotary Handle Control: Built with a rugged, three-position rotary knob (ON / OFF / TRIPPED). The handle can be physically padlocked in the “OFF” position, serving as a secure disconnect for strict plant Lockout/Tagout (LOTO) safety protocols.EverLink BTR Terminals: Utilizes Schneider’s patented wire-clamping technology. An internal spring mechanism counteracts copper wire “creepage” (loose settling over time) caused by machinery vibrations, entirely preventing hot-spot panel fires.Extreme Breaking Capacity (100kA): Because the load current is highly optimized for this robust frame, this breaker can safely extinguish intense short-circuit spikes up to a massive $100,000A$ at 400/415V without failing or breaking down.Compatible Mechanisms and ComponentsThe current/frame footprint of the GV3P32 integrates cleanly with standard industrial automation control gear:1. In-Panel Equipment CompatibilityTeSys Deca Contactors: Natively pairs side-by-side or stacks with magnetic contactors like the LC1D32 or LC1D40A using a specialized busbar link connector. This creates an integrated, space-saving motor starter block.GV3 Auxiliary Signal Modules: Accepts front-mounting (e.g., GVAE11) or side-clamping (GVAN11) auxiliary blocks to push real-time physical telemetry (ON/OFF status) directly to remote industrial PLCs.Undervoltage / Shunt Trips: Can be augmented with a GV3AS shunt trip or GVAU undervoltage release internally, allowing an emergency stop circuit or safety relay to snap the breaker open automatically from across the plant floor.2. Machinery and Mechanical Loads It ProtectsThe 23A to 32A calibration range renders this MPCB ideal for protecting standard three-phase electric induction motors operating at 15 kW (20 HP) under standard 400/415V conditions, including:Medium-Duty Industrial Machining Equipment: Protects the individual motors running industrial wood saws, localized metal cutting tools, and milling lathes.Conveyor & Material Handling Systems: Drives mechanical assembly loops, heavy packaging lanes, and factory sorting belts.Fluid Transfer & Submersible Pumps: Safeguards industrial clean-water booster pumps, waste fluid transfer systems, and small hydraulic units.Commercial Ventilation Fans: Runs heavy exhaust air fans, centrifugal kitchen smoke extractors, and air curtains drawing under 32 Amps.
