Product DescriptionThe Schneider TeSys Deca LC1D40 is an industrial-grade three-pole magnetic contactor used for heavy-duty electrical switching. It uses an internal electromagnetic coil to snap shut high-capacity contacts, safely establishing or interrupting electrical power to massive machinery. The TeSys Deca series features modern EverLink terminal blocks, which maintain constant pressure on the power cables over time to prevent overheating from loose connections.Key Features3-Pole (3NO) Power Contacts: Designed to simultaneously switch all three live phases of a three-phase power grid.40A Current Rating (AC-3 / AC-3e): Explicitly rated to handle up to 40 Amps of continuous inductive load. This makes it perfect for managing high-inrush currents when large motors start up.Integrated Auxiliary Contacts: Features built-in 1NO (Normally Open) + 1NC (Normally Closed) auxiliary contacts right on the front face for control logic, interlocking, or indicator lights.Flexible Control Coil: The internal operating electromagnet ($A1/A2$ terminals) is available in common voltages (like 24V DC, 110V AC, or 220V/230V AC) to match your specific control circuit infrastructure.Compatible Mechanisms and ComponentsAs a high-capacity power actuator, this contactor functions as the primary bridge between control systems and heavy machinery:1. In-Panel Component CompatibilityThermal Overload Relays: Directly compatible with clip-on Schneider LRD series thermal overload relays (specifically the LRD340 to LRD355 range or LR3D electronic relays). Combining them creates a complete motor starter assembly that protects motors from burning out due to phase loss or mechanical overloading.Auxiliary Contact Blocks: Expandable via top-mounted adder blocks (such as the LADN11 or LADN22 arrays) to add up to 4 more signaling paths for PLC feedback or panel lights.Surge Suppressor Blocks: Natively accepts snap-on RC circuits, varistors, or diode limiters across the $A1/A2$ coil terminals to protect upstream electronics from inductive voltage spikes when the contactor switches off.2. Machinery and Mechanical Loads It ControlsA 3P 40A contactor is perfectly sized to safely handle the operational load of:Three-Phase Induction Motors: Remotely starts and cycles medium-duty industrial motors up to 18.5 kW (25 HP) at 400/440V, such as those powering conveyor systems, industrial exhaust fans, and car lifts.High-Capacity Water Pumps: Used inside agricultural irrigation controllers, commercial building booster stations, and deep-well submersible pump panels.Industrial Heating Elements: Safely switches large resistive loads up to 60 Amps (under AC-1 classification), such as commercial bakery ovens and plastic extrusion heaters.HVAC Compressors: Manages the main power cycling to large commercial central air conditioning chillers and condenser fan arrays.
